Camera

Sensor

1/2.7", progressive scan, 2megapixel, CMOS

Lens

2.8mm@F1.6

4.0mm@F1.6

DORI Distance

Lens

Detect(m)

Observe(m)

Recognize(m)

Identify(m)

2.8mm

42

16.8

8.4

4.2

4mm

60

24

12

6

Angle of view(H)

112.7°

86.5°

Angle of View (V)

60.1°

44.1°

Angle of View (O)

146.5°

106.4°

Adjustment angle

Pan: 0°~360°

Tilt: 0°~90°

Rotate: 0°~360°

Shutter

Auto/Manual, 1~1/100000 s

Minimum Illumination

Colour: 0.005 Lux (F1.6, AGC ON)
0 Lux with IR

Day/Night

IR-cut filter with auto switch (ICR)

Digital noise reduction

2D/3D DNR

S/N

>52dB

IR Range

Up to 30m (98 ft) IR range

Defog

Digital Defog

WDR

DWDR

Video

Video Compression

Ultra 265, H.264, MJPEG

H.264 code profile

Baseline profile, Main Profile, High Profile

Frame Rate

Main Stream:2MP (1920×1080): Max. 30 fps;
Sub Stream:2MP (1920×1080): Max. 30 fps;
Third Stream:D1 (720×576): Max. 30 fps

HLC

Supported

BLC

Supported

9:16 Corridor Mode

Supported

OSD

Up to 8 OSDs

Privacy Mask

Up to 8 areas

ROI

Up to 8 areas

Motion Detection

Up to 4 areas

Smart

Behavior Detection

Intrusion, cross line, motion detection

Intrusion

Enter and loiter in a pre-defined virtual region

cross line

Cross a pre-defined virtual line

motion detection

Moving within a pre-defined virtual region

Recognition

Face detection?Audio detection

Intelligent Identification

Defocus, Scene Change, Object Left, Object Moving

Statistical Analysis

People counting

General Function

Watermark, IP Address Filtering, Tampering Alarm, Access Policy, ARP Protection, RTSP Authentication, User Authentication

Network

Protocols

IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x

Compatible Integration

ONVIF(Profile S, Profile G, Profile T), API

Interface

Network

1 RJ45 10M/100M Base-TX Ethernet

General

Power

12 V DC±25%, PoE (IEEE802.3 af)

Power consumption: Max 4.5W

Dimensions (Ø x H)

Φ126 x 94 mm (Ø5.0” x 3.7”)

Weight

0.45 kg (0.99lb)

Operating Conditions

-35°C ~ +60°C (-31°F ~ 140°F), Humidity:10%~95% RH(non-condensing)

Ingress Protection

IP67
